Cox 196cc Vertical - Recoil - CPV200-1
Cox 196cc Vertical - Recoil - CPV200-1
Regular price
$414.37
Regular price
$0.00
Sale price
$414.37
Unit price
/
per
Taxes included.
Not Stocked – Order In
Lead time: 2–14 business days
Couldn't load pickup availability
COX CPV200-1 Vertical Shaft Engine – 5hp (Recoil Start)
Overview The CPV200-1 is a 196cc vertical shaft petrol engine designed for residential and light commercial applications. With a recoil start system and 3/4" vertical shaft, it delivers 5hp and 10 Nm of torque. Its compact dimensions and CE, EC(V), EPA, and CARB certifications make it ideal for lawn mowers and similar equipment requiring reliable ignition and consistent performance.
Key Features
- 5hp Rated Power at 3800 rpm
- 196cc Displacement
- 10 Nm Max Torque
- 3/4" Vertical Shaft
- Recoil Start System
- Engine Oil Capacity: 0.6 L (SAE 10W-30 recommended)
- Engine Dimensions: 435 × 365 × 415 mm
- Net Weight: 11 kg
- Certifications: CE, EC(V), EPA, CARB
- Applications: lawn mowers, light-duty vertical shaft machinery
Specifications
| Attribute | Detail |
|---|---|
| Model | CPV200-1 |
| Product Type | Vertical Shaft Engine |
| Displacement | 196 cc |
| Rated Power | 5 hp |
| Rated Torque | 10 Nm |
| Cylinder Bore x Stroke | 70 × 51 mm |
| Max Output Speed | 3800 rpm |
| Idle Speed | 1800 ± 200 rpm |
| PTO Shaft Size | 3/4" Vertical Shaft |
| Starting System | Recoil |
| Engine Oil Capacity | 0.6 L |
| Recommended Oil | SAE 10W-30 |
| Specific Fuel Consumption | ≤ 414 g/kW·h |
| Engine Dimensions (L×W×H) | 435 × 365 × 415 mm |
| Net Weight | 11 kg |
| Certifications | CE, EC(V), EPA, CARB |
| SKU | CPV200-1 |
