COX
Cox 3hp Vertical - Recoil - CPV140-1
Cox 3hp Vertical - Recoil - CPV140-1
Regular price
$292.49
Regular price
$0.00
Sale price
$292.49
Unit price
/
per
Taxes included.
Not Stocked – Order In
Lead time: 2–14 business days
Couldn't load pickup availability
COX CPV140-1 Vertical Shaft Engine – 3hp (Recoil Start)
Overview The CPV140-1 is a compact 141cc vertical shaft petrol engine designed for light-duty applications such as lawn mowers. With a recoil start system and 3/4" shaft, it delivers 3hp and 6.5 Nm of torque. Its CE, EC(V), EPA, and CARB certifications ensure compliance and reliability for residential and commercial use.
Key Features
- 3hp Rated Power at 3800 rpm
- 141cc Displacement
- 6.5 Nm Max Torque
- 3/4" Vertical Shaft
- Recoil Start System
- Engine Oil Capacity: 0.5 L (SAE 10W-30 recommended)
- Engine Dimensions: 380 × 320 × 370 mm
- Net Weight: 7.8 kg
- Certifications: CE, EC(V), EPA, CARB
- Applications: lawn mowers
Specifications
| Attribute | Detail |
|---|---|
| Model | CPV140-1 |
| Product Type | Vertical Shaft Engine |
| Displacement | 141 cc |
| Rated Power | 3 hp |
| Rated Torque | 6.5 Nm |
| Cylinder Bore x Stroke | 65 × 42.5 mm |
| Max Output Speed | 3800 rpm |
| Idle Speed | 1800 ± 200 rpm |
| PTO Shaft Size | 3/4" Vertical Shaft |
| Starting System | Recoil |
| Engine Oil Capacity | 0.5 L |
| Recommended Oil | SAE 10W-30 |
| Specific Fuel Consumption | ≤ 410 g/kW·h |
| Engine Dimensions (L×W×H) | 380 × 320 × 370 mm |
| Net Weight | 7.8 kg |
| Certifications | CE, EC(V), EPA, CARB |
| SKU | CPV140-1 |
