Cox 420cc Horizontal Recoil / E-Start CPH420-3
Cox 420cc Horizontal Recoil / E-Start CPH420-3
Regular price
$786.34
Regular price
$0.00
Sale price
$786.34
Unit price
/
per
Taxes included.
Not Stocked – Order In
Lead time: 2–14 business days
Couldn't load pickup availability
COX CPH420-3 Horizontal Shaft Engine – 12.5hp (Recoil + E-Start)
Overview The CPH420-3 is a powerhouse petrol engine built for heavy-duty applications across farming, construction, and industrial machinery. With a 420cc displacement and 27 Nm of torque, it features a 1" keyway shaft and dual recoil/electric start system. Certified by CE, EC(V), EPA, and CARB, it’s engineered for reliability and performance in high-demand environments.
Key Features
- 12.5hp Rated Power at 3600 rpm
- 27 Nm Max Torque
- 420cc Displacement
- 90 × 66 mm Bore/Stroke
- 1" Keyway Shaft (Horizontal PTO)
- Dual Start System: Recoil + Electric
- Fuel Tank Capacity: 7.5 L
- Engine Oil Capacity: 1.1 L (SAE 10W-30 recommended)
- Engine Dimensions: 480 × 425 × 505 mm
- Net Weight: 30.5 kg
- Certifications: CE, EC(V), EPA, CARB
- Applications: generators, grain lifters, construction machinery
Specifications
| Attribute | Detail |
|---|---|
| Model | CPH420-3 |
| Product Type | Horizontal Shaft Engine |
| Displacement | 420 cc |
| Rated Power | 12.5 hp |
| Rated Torque | 27 Nm |
| Cylinder Bore x Stroke | 90 × 66 mm |
| Max Output Speed | 3600 rpm |
| Idle Speed | 1650 ± 150 rpm |
| PTO Shaft Size | 1" Keyway Shaft |
| Starting System | Recoil + Electric Combo |
| Engine Oil Capacity | 1.1 L |
| Recommended Oil | SAE 10W-30 |
| Fuel Tank Capacity | 7.5 L |
| Specific Fuel Consumption | ≤ 370 g/kW·h |
| Engine Dimensions (L×W×H) | 480 × 425 × 505 mm |
| Net Weight | 30.5 kg |
| Certifications | CE, EC(V), EPA, CARB |
| SKU | CPH420-3 |
