Cox 3.5hp Horizontal 3/4" Shaft CPH150-2
Cox 3.5hp Horizontal 3/4" Shaft CPH150-2
Regular price
$297.07
Regular price
$0.00
Sale price
$297.07
Unit price
/
per
Taxes included.
Not Stocked – Order In
Lead time: 2–14 business days
Couldn't load pickup availability
COX CPH150-2 Horizontal Shaft Engine – 3.5hp
Overview The CPH150-2 is a compact, high-performance petrol engine designed for lawn and garden equipment, pressure washers, and portable generators. With a cast iron-lined cylinder and 3/4" keyway shaft, it delivers 3.5hp at 4000 rpm and 7.2 Nm of torque. Lightweight and EPA/CE/CARB certified, it’s built for reliability across a wide range of applications.
Key Features
- 3.5hp Rated Power at 4000 rpm
- 7.2 Nm Max Torque
- 149cc Displacement
- Cast Iron Cylinder Liner for durability
- 3/4" Keyway Shaft (Horizontal PTO)
- Recoil Start System
- Fuel Tank Capacity: 1.2 L
- Engine Oil Capacity: 0.5 L (SAE 10w-30 recommended)
- Compact Dimensions: 360 × 315 × 390 mm
- Net Weight: 10kg
- Certifications: CE, EC(V), EPA, CARB
- Applications: tillers, pressure washers, generators
Specifications
| Attribute | Detail |
|---|---|
| Model | CPH150-2 |
| Product Type | Horizontal Shaft Engine |
| Displacement | 149 cc |
| Rated Power | 3.5 hp |
| Rated Torque | 7.2 Nm |
| Cylinder Bore x Stroke | 65 × 45 mm |
| Max Output Speed | 4000 rpm |
| Idle Speed | 1800 ± 200 rpm |
| PTO Shaft Size | 3/4" Keyway Shaft |
| Starting System | Recoil |
| Engine Oil Capacity | 0.5 L |
| Recommended Oil | SAE 10w-30 |
| Fuel Tank Capacity | 1.2 L |
| Specific Fuel Consumption | ≤ 400 g/kW·h |
| Engine Dimensions (L×W×H) | 360 × 315 × 390 mm |
| Net Weight | 10 kg |
| Certifications | CE, EC(V), EPA, CARB |
| SKU | CPH150-2 |
