COX CPV200-2 Vertical Shaft Engine – 5hp (Recoil + E-Start)
COX CPV200-2 Vertical Shaft Engine – 5hp (Recoil + E-Start)
Regular price
$379.50
Regular price
Sale price
$379.50
Unit price
/
per
Taxes included.
Not Stocked – Order In
Lead time: 2–14 business days
Couldn't load pickup availability
COX CPV200-2 Vertical Shaft Engine – 5hp (Recoil + E-Start)
Overview The CPV200-2 is a 196cc vertical shaft petrol engine designed for residential and light commercial applications. With both recoil and electric start systems, it delivers 5hp and 10 Nm of torque through a 3/4" vertical shaft. Certified to CE, EC(V), EPA, and CARB standards, it’s ideal for lawn mowers and similar equipment requiring reliable ignition and compact power.
Key Features
- 5hp Rated Power at 3800 rpm
- 196cc Displacement
- 10 Nm Max Torque
- 3/4" Vertical Shaft
- Dual Start System: Recoil + Electric
- Engine Oil Capacity: 0.6 L (SAE 10W-30 recommended)
- Engine Dimensions: 435 × 365 × 415 mm
- Net Weight: 11 kg
- Certifications: CE, EC(V), EPA, CARB
- Applications: lawn mowers, light-duty vertical shaft machinery
Specifications
| Attribute | Detail |
|---|---|
| Model | CPV200-2 |
| Product Type | Vertical Shaft Engine |
| Displacement | 196 cc |
| Rated Power | 5 hp |
| Rated Torque | 10 Nm |
| Cylinder Bore x Stroke | 70 × 51 mm |
| Max Output Speed | 3800 rpm |
| Idle Speed | 1800 ± 200 rpm |
| PTO Shaft Size | 3/4" Vertical Shaft |
| Starting System | Recoil + Electric Combo |
| Engine Oil Capacity | 0.6 L |
| Recommended Oil | SAE 10W-30 |
| Specific Fuel Consumption | ≤ 414 g/kW·h |
| Engine Dimensions (L×W×H) | 435 × 365 × 415 mm |
| Net Weight | 11 kg |
| Certifications | CE, EC(V), EPA, CARB |
| SKU | CPV200-2 |
